kualitas U760E U760F Transmisi otomatis Bagian belakang Multi-disc clutch pabrik

U760E U760F Transmisi otomatis Bagian belakang Multi-disc clutch

Ringkasan Produk

Function: Transfers Quattro AWD torque to rear wheels via crown wheel/pinion (4.25:1 ratio) with integrated electronic differential lock. Key Features: Hypoid Gearset: Case-hardened steel (HRC 60+) with lapped contact pattern Haldex Coupling: Gen 5 multi-plate clutch (0-100% rear bias) Thermal Management: Temperature sensor triggers cooling protocol (>250°F) Failure Modes: Bearing Pitting: Contaminated fluid (G 055 529 A2) causes whine Clutch Pack Wear: Leads to AWD

Properti Dasar

Nama Merek: Audi

Nomor Model: /

Properti Perdagangan

Jumlah pesanan minimum: 1

Harga: 0-1000

Ketentuan Pembayaran: T/T

Tag:

Transformator torsi transmisi

Suku Cadang Transmisi Otomatis

Penggabungan kopling transmisi

Deskripsi Produk

- - - Fungsi: Mentransfer torsi Quattro AWD ke roda belakang melalui roda mahkota/pinion (rasio 4.25:1) dengan pengunci diferensial elektronik terintegrasi.

      Fitur Utama:
      - Roda Gigi Hipoid: Baja yang dikeraskan (HRC 60+) dengan pola kontak yang dilapis
      - Kopling Haldex: Kopling multi-pelat Gen 5 (bias belakang 0-100%)
      - Manajemen Termal: Sensor suhu memicu protokol pendinginan (>250°F)
      Mode Kegagalan:
      - Pitting Bantalan: Fluida yang terkontaminasi (G 055 529 A2) menyebabkan dengungan
      - Keausan Paket Kopling: Menyebabkan pelepasan AWD (kode P189C)
      - Kebocoran Segel: Fluida diferensial bermigrasi ke unit Haldex
      Spesifikasi Kritis:
      1. Backlash: 0.08-0.12mm (memerlukan indikator dial)
      2. Preload pinion: 1.2-1.8 Nm torsi rotasi
      Tips Pro: Lakukan reset adaptasi melalui ODIS setelah servis – mencegah peringatan "AWD malfunction" palsu.

U760E U760F Transmisi otomatis Bagian belakang Multi-disc clutch 1

U760E U760F Transmisi otomatis Bagian belakang Multi-disc clutch 2

Rincian produk

Menyoroti:

U760E Bangunan kopling multi-disk belakang

Perangkat kopling multi-disk belakang

Year：: 2020-2022

MODEL：: /

SIZE:: 55x45x40cm

Brand：: AUDI

Item Weight:: 35kg

ＯＥＮＯ: 0CQ525010R

Applicable Brand:: Audi ： 2020-2022: A3/S3/Sportb./Lim./Qu

Mrs. Kinny

Foreign trade Manager

E-mail: admin@transmesun.com
Telp: +8618665691829
ada apa: 8618665691829
Wechat wechat: +8618665691829
