Rakitan pompa transmisi 10R80 komponen cor baru merek RFHL3P-7F335
Ringkasan Produk
Application: Ford 10R80 10-speed RWD/4WD (2017+ F-150/Raptor, torque to 800Nm). Design: High-pressure gerotor pump (hardened steel inner/outer rotors, T6 aluminum housing). Integrated electronic pressure control (EPC) solenoid (PWM-regulated, 0–120 psi). Key Specs: Flow rate: 20L/min @ 2000 RPM (5µm filtration critical). Clearances: 0.018–0.025mm rotor (replace if >0.08mm). Relief valve: 145psi burst protection. Failure Modes: Cavitation erosion (low fluid/air ingress).
Properti Dasar
Nama Merek:
Ford
Nomor Model:
10R80
Properti Perdagangan
Jumlah pesanan minimum:
1
Harga:
0-1000
Ketentuan Pembayaran:
T/T
Deskripsi Produk
-
Aplikasi:Ford 10R80 10 kecepatan RWD / 4WD (2017 + F-150 / Raptor, torsi hingga 800Nm).
-
Desain:
-
Pompa gerotor tekanan tinggi(rotor internal / eksternal baja keras, T6 aluminium casing).
-
Solenoid kontrol tekanan elektronik terintegrasi (EPC)(PWM-diatur, 0 ‰ 120 psi).
-
-
Spesifikasi utama:
-
Tingkat aliran:20L/min @ 2000 RPM (5μm filtrasi kritis).
-
Izin:0.018 ∼0.025 mm rotor (ganti jika > 0.08 mm).
-
Katup bantuan:Perlindungan ledakan 145psi.
-
-
Mode kegagalan:
-
Erosi kavitasi(pendaratan cairan/udara rendah).
-
Penyumbatan solenoid(sisa-sisa dari kopling yang usang).
-
Porositas perumahan(kecacatan pengecoran dalam batch awal).
-
Catatan:MembutuhkanMercon ULV fluida; 2022+ casting telah direvisi bleed passages.
Rincian produk
Menyoroti:
10R80 transmission pump assembly
,brand new transmission oil pump
,RFHL3P-7F335 cast component pump
Year：:
2017-2019
MODEL：:
10R80
SIZE::
35X25X25CM
Brand：:
Ford
Item Weight::
7kg
ＯＥＮＯ:
24278077;JL3Z-7A130-A
Applicable Brand::
FORD Mustang
